59.2V （16S）Li-Ion Battery BMS
WS-24S60A-035（16S）
Item	Specification
1	Voltage	Charge Voltage	DC：67.2V CC/CV
			4.20±0.025V
2	Current		84±10mA
		Self Discharge(Single Cell)	≤20μA
		Max Constant Charge Current	30A
		Max Constant Discharge Current	30A
3	Over Charge（Single Cell）	Over Charge Voltage	4.25±0.025V
		Overcharge Detection Delay Time	0.5S—1.5S
		Overcharge Recovery Voltage	4.05±0.05V
4	Over Discharge（Single Cell）	Overdischarge Detection Voltage	2.50±0.062V
		Over Discharge Detection Delay Time	10mS—150mS
		Over-Discharge Recovery Voltage	2.50±0.062V
5	Over Current	Over Discharge Current Detection Voltage	0.62V
		Over Discharge Current Detection Current	150±20A
		Overcurrent Detection Delay Time	5ms—15ms
		Recovery Status	Disconnect The Load, Automatic Recovery
6	Short Circuit	Detection Status	Short Circuit
		Detection Delay Time	200-500us
		Recovery Status	Disconnect The Load, Automatic Recovery
7	Internal Resistance	Protection（MOSFET）	≤20mΩ
8	Temperature	Operating Temperature Range	-40～+85℃
		Storage Temperature Range	-40～+125℃

59.2V(16S) Li-ion lithium battery BMS
