Input: AC 90~264V 50/60Hz 14A
Output: DC 25.2~84V 1200W max
Power factor: PF＞0.96 @ 220V full load
Multi-protection: OVP, OTP, SCP, RP
Working mode: Pre-charge, CC, CV and Cut-off（4 stages）
Casing material and cooling: Aluminum alloy shell; fan cooling
Safety approvals: CE, FCC
Dimensions & Weight: 278 x 145 x 47.7 mm / 1.8 kg
Suitable for: 25.6V~64V, 8~20S LiFePO4 battery packs
Applications: Energy Storage Systems, Electric Vehicles, AGVs, Robots, etc
| Model | Output Voltage | Output Current | Suitable Device | |
|---|---|---|---|---|
| G1300-288400 | 28.8V | 40.0A | Energy Storage Systems | |
| G1300-360330 | 36.0V | 33.0A | EV, Robots, AGVs | |
| G1300-432270 | 43.2V | 27.0A | Energy Storage Systems | |
| G1300-576200 | 57.6V | 20.0A | EV, Robots, AGVs | |
| G1300-720166 | 72.0V | 16.6A | Energy Storage Systems |
