84.0V 20S lithium charger

Model P/N list
Model P/N	CV	CC	For Battery
G1200-252400	25.2V	40.0A	6S Li-ion
G1200-294400	29.4V	40.0A	7S Li-ion
G1200-420280	42.0V	28.0A	10S Li-ion
G1200-546200	54.6V	20.0A	13S Li-ion
G1200-588200	58.8.0V	20.0A	14S Li-ion
G1200-672180	67.2V	18.0A	16S Li-ion
G1200-840130	84.0V	13.0A	20S Li-ion

8615986775944 86755-86299563

Description

Input: AC 90~264V 50/60Hz 15A
Output: DC 25.2~84V 1200W max
High convert efficiency: 95% @220V full load
High power factor: 95% @220V full load
Multi-protections: OVP、OCP、OTP、Shorted and Reversed
Work mode: Pre-charge、CC、CV and Cut-off（Four stages）
LED Indicator: Digital LCD display voltage，current and charging process
Casing material and cooling: Plastic housing，fan cooling
Safety approval: CB CE FCC
Size&weight: 280 x 135 x 60mm/3.0Kg
Suit for: 22.2V~74V, 6~20cells Lithium/LiPo battery packs
Application: Power Tool,Electrical Bike,Mobile Lamp,Security system and so on
